Double Moulds Pressed Wood Pallet Machine

Double moulds pressed wood pallet machine is designed to produce compressed wood pallets, which using wood waste materials.
We specialize in the fabrication of these wood pallet machines for a decade. And we are in a leading position in the field of new compressed wood pallet machine for wood waste recycling in China.

Product Details

We are one of the leading project suppliers for new compressed wood pallet machine for wood waste recycling in Spain. And we work closely with our customers to fulfill their specific needs for a customized solution.

Double moulds pressed wood pallet machine has a reasonable design structure, adopts four-way synchronous positioning, precise balance of clamping, fast pressurization with liquid filling.

Double moulds pressed wood pallet machine can be fully pressurized in 30 seconds, convenient and simple operation, just lay the wood chips flat in the processing touch tool. Just pressing the work button, pallet machine can automatically complete the whole process of pressing, limiting pressure, lowering pressure, holding pressure, timing, unloading, demoulding, and lifting in place.

The time for processing a pallet holding pressure curing is about 350 seconds, a moulding machine can process about 240 pieces of pallets in 24 hours. The finished pressed wood pallets are beautiful in appearance, available for small specification production needs, and can also be equipped with multiple machines for processing.

Application

The machine can use materials to make pressed wood pallet, such as waste wood, scraps of the wood, sawdust, wood chips, wood shavings, big chips, raw wood, burned forest, logs, wood board, branches, timber, wood flakes, and waste pallets, and so on.

Features of Double moulds pressed wood pallet machine
New compressed wood pallet machine for wood waste recycling in Spain is vertical structure of the four-column hydraulic press machine. And it consists of the frame, oil cylinder, hydraulic power system and electrical system, and other accessories.

1. Structure.
The frame of new compressed wood pallet machine for wood waste recycling in Spain adopts the 3-beam 4-column structure with good strength, rigidity, and precision retaining ability.

2. Control system.
Control cabinets can be automatic and manual control.
2.1 Automatic control mode: press the automatically start button, then the machine will complete the whole process of compressed wood pallet production.
2.2 Manual control mode: manual button can control the mold up and down and unload the compressed wood pallet.

3. Safe device.
The motor controlling parts equip thermal protectors and breakers. So it can protect the motor will not break when overload and have the protection measures of overload and short circuit.
It has an overflow valve for the rise and fall of the cylinder to ensure overload pressure.
Overpressure protection: the equipment will stop working when the pressure is overset pressure

Technical parameters of double moulds pressed wood pallet machine:

Double Moulds Wood Pallet Machine
Model TYSYJ-1000/1200
Voltage Customized
Capacity 240 pieces/day (24hours)
Power 22 kW
Hydraulic cylinder diameter 350 mm
Hydraulic cylinder quantity 4 pieces
Pressure 0-1200 tons (adjustable)
Shaping cycle 300 seconds
Weight 30 tons
Dimension 4200*2200*3500 mm
Remarks: it includes two sets normal mould along with one set machine.
